Utilities Menu 62
If Done is selected without locking the security settings, the user will be prompted that the security settings will not be
locked.
8.6 Error Log
View up to 50 previously set error codes.
Press the button then use the soft key to select Utilities > Error Log.
Figure 8.11 Error Log
Errors are placed in the order that they were encountered. 1 being the most recent.
The error log displays up to 50 error codes.
After reaching 50 error codes no more codes will be reported in the error log.
To continue ling error codes the error log list must be cleared
The error log can be saved into a USB ash drive connected to the USB port on the front panel.
Save the log by:
Pressing the button then use the soft key to select Utilities > Error Log > Save .
Use the rotary knob and the button to navigate through the le path of the USB. Once the desired location has
been found select Save by pressing the softkey furthest to the left.
Clear the data log by:
Pressing the button then use the soft key to select Utilities > Error Log > Clear All > Yes.
Code Description
0x0001 Over Voltage Protection Triggered
0x0002 Over Current Protection Triggered
0x0004 Over Temperature Protection Triggered
0x0008 Sense not connected
Table 8.1 Status Code
