Battery Charge Function 43
6.3.3 Stop Ah
Set a Ah stop time.
Press the button then use the soft key to select List/Battery > Batt Test Setup > Fail Safe Settings >
Stop Ah.
– Use the numeric keypad or rotary knob to set the desired stop time. (0 to 9999.99 s)
– Press the to set the stop time.
Upon starting the Battery Charge function and turning on the output a timer will be set. The output will turn o once
the timer reaches 0 or when another stop parameter is reached.
6.3.4 Stop Wh
Set a Wh stop time.
Press the button then use the soft key to select List/Battery > Batt Test Setup > Fail Safe Settings >
Stop Wh.
– Use the numeric keypad or rotary knob to set the desired stop time. (0 to 9999.99 s)
– Press the to set the stop time.
Upon starting the Battery Charge function and turning on the output a timer will be set. The output will turn o once
the timer reaches 0 or when another stop parameter is reached.
6.3.5 Over Voltage Protection (OVP)
Over voltage protection is always enabled, however the user can set the OVP voltage limits.
Press the button then use the soft key to select List/Battery > Batt Test Setup > Fail Safe Settings >
OVP.
– Use the numeric keypad or rotary knob to set the desired OVP limit.
– Press the
When OVP protection is tripped during operation, the output will be de-rated to 0 V and the icon
will appear.
