BK Precision 9240 Series User Manual

List Mode
The 9240 series is capable of storing up to 10 programmable lists in the internal memory. Each list can have up to 100
congurable steps.
If all ten list numbers are taken, a list can also be saved to a USB drive. Lists can be loaded from a USB drive, allowing
for a larger collection of programmed lists.
5.1 List Setup
Press the button then use the soft key to select List/Battery > List Setup.
Figure 5.1 List Setup
Use the softkeys to set the following parameters.
List State:
Toggle list state On/O for the selected channel.
List Number:
Select a list program from the memory to run on the channel.
Use the numeric keypad or rotary knob to select list number.
Press to assign the list to a channel.
