Output Conguration 28
DO NOT at any time disconnect the wires from the S+ and S- terminals to the DUT while
output is enabled (ON). Doing so may damage the power supply and cause unstable output.
Remote sense is disabled by default, to enable remote sense:
1. Press the button then use the soft key to select Output cong > Output Settings.
2. Press Remote Sense using the soft key to enable remote sense.
4.2.2 Output Timer
An output timer can be set. When the output timer is enabled, an hourglass icon will be displayed next to the output
state icon. The timer countdown will begin when the output is enabled. The output is disabled when the countdown
reaches 0. The timer can be set from 1 second to 99 hours 59 minutes and 59 seconds.
Follow the steps below to enable and set the output timer:
1. Press the button then use the soft key to select Output cong > Output Settings.
2. Push Timer State to enable the timer.
3. Select Timer Setting and set a desired time for the output to be enabled using the numeric keypad or rotary knob.
The timer format is: HH:MM:SS. Use the keys to move the cursor.
4.2.3 Voltage Slew
The rising voltage slew rate can be set in volts per second. The voltage slew range can be set from 0.001 V/s to
3200.0 V/s.
1. Press the button then use the soft key to select Output cong > Output Settings.
2. Select Voltage Slew and use the numeric keypad or rotary knob to adjust the slew rate value. Press to conrm input.
4.2.4 Current Slew
The rising current slew rate can be set in amps per second. The current slew range can be set from 1 A/s to 800
A/s.
1. Press the button then use the soft key to select Output cong > Output Settings.
2. Select Next Pg. > Current Slew and use the numeric keypad or rotary knob to adjust the slew rate value.
Press to conrm input.
