Basic Front Panel Operation 22
Figure 3.2 Numeric Keys
3.1.4 Output Control
The button toggles the output On/O. When output is enabled, the ON button will turn green and the
supply will display the state of the channel.
represents constant current mode. represents constant voltage mode. When output is disabled, the
channel state will display .
