Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range Factory s e tting
IdC2
*
(1) (3)
[DC inject. level 2]
0.1 In (2) to
[DC inje ct. level 1]
(IdC)
0.5 In (2)
NOTICE
OVERHEATING AND DAMAGE TO THE MOTOR
Verify that the connected m otor is properly rated for the DC injection current to be applied in term s of am ount
and tim e in order to avoid overheating and dam age to the m otor.
Failure to follow these instructions can result in equipment damage.
Injection current activated by logic input or selected as stop mode, once period of time
[DC injection time 1]
(tdI) has
elapsed.
This parameter can be accessed if
[Type of stop]
(Stt) is set to
[DC inje ction]
(dCI) or if
[DC injection as sign.]
(dCI) is not
set to
[No]
(nO).
tdC
*
(1) (3)
[DC injection time 2]
0.1 to 30 s 0.5 s
NOTICE
OVERHEATING AND DAMAGE TO THE MOTOR
Verify that the connected m otor is properly rated for the DC injection current to be applied in term s of am ount
and tim e in order to avoid overheating and dam age to the m otor.
Failure to follow these instructions can result in equipment damage.
Maximum injection time
[DC inje ct. le vel 2]
(IdC2) for injection, selected as stop mode only. This
parameter can be accessed if
[Stop type]
(Stt) is set to
[DC injection]
(dCI).
dOtd
nSt
rMp
[Dis. operat opt code]
[Ram p stop]
(rMp)
Disable operation stop mode.
[Freewheel]
(nSt): Disable drive function
[Ram p s top]
(rMp): Ramp stop then disable drive function
(1)
The parameter can also be accessed in the
[SETTINGS]
(SEt-)
menu.
(2)
In corresponds to the rated drive current indicated in the Installation manual and on the drive nameplate.
(3)
These settings are independent of the
[AUTO DC INJECTION]
(AdC-) function.
These parameters only appear if the corresponding function has been selected in another menu. When the parameters can
also be accessed and adjusted from w ithin the configuration menu for the corresponding function, their description is detailed
in these menus, on the pages indicated, to aid programming.
Parameter that can be modified during operation or w hen stopped.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > FUN- > STT-
*
