Configuration Mode (ConF)
260
Code Nam e / De s cription Adjus tment range Factory s e tting
UPL
*
[Prevention level]
133 to 261 V According to drive rating
Undervoltage prevention level setting in Volts, w hich can be accessed if
[UnderV. prevention]
(StP)
is not
[No]
(nO). The
adjustment range and factory setting are determined by the drive voltage rating and the
[M ains voltage]
(UrES)
value.
StM
*

[Max stop time]
0.01 to 60.00 s 1.00 s
Ramp time if
[Unde rV. preve ntion]
(StP) is set to
[Ram p s top]
(rMP).
tbS
*

[DC bus maintain tm]
1 to 9,999 s 9,999 s
DC bus maintain time if
[Unde rV. preve ntion]
(StP) is set to
[DC M aintain]
(MMS).
FLt
-
[FAULT MANAGEMENT]
(continued)
tIt
-
[IGBT TESTS]
Strt
nO
YES
[IGBT test]
[No]
(nO)
[No]
(nO): No test
[Ye s ]
(YES): The IGBTs are tested on pow er up and every time a run command is sent. These tests cause a slight delay (a
few ms). In the event of a detected fault, the drive w ill lock. The follow ing faults can be detected:
-
Drive output short-circuit (terminals U-V-W): SCF display.
-
IGBT inoperable: xtF, w here x indicates the number of the IGBT concerned.
-
IGBT short-circuited: x2F, where x indicates the number of the IGBT concerned.
FLt
-
[FAULT MANAGEMENT]
(continued)
LFL
-
[4
-
20mA LOSS]
LFL3
nO
YES
Stt
LFF
rLS
rMP
FSt
dCI
[AI3 4-20mA loss]
[Ignore ]
(nO)
[Ignore]
(nO): Detected fault ignored. This is the only possible configuration if
[AI3 m in. value]
(CrL3)
page 134 is not
greater than 3 mA
[Freew heel]
(YES): Freew heel stop
[Per
STT]
(
Stt
):
Stop
according
to
configuration
of
[Type
of
stop]
(
Stt
)
page
173,
without
fault
tripping.
In
this
case,
the
fault relay does not open and the drive is ready to restart as soon as the detected fault disappears, according to the restart
condition s
of
the
active
command
channel
(for
example,
according
to
[2/3
wire
control]
(
tCC
)
and
[2
wire
type]
(
tCt
)
page
125
if control is via the terminals). Configuring an alarm for this detected fault is recommended (assigned to a logic
output, for example) in order to indicate the cause of the stop
[Fallback s pd]
(LFF): Change to fallback speed, maintained as long as the detected fault persists and the run command
has not been removed (1)
[Spd m aint.]
(rLS):
The drive maintains the speed being applied w hen the detected fault occurred, as long as the detected
fault is present and the run command has not been removed (1)
[Ram p s top]
(rMP): Stop on ramp
[Fast s top]
(FSt): Fast stop
[DC
injec t ion ]
(
dC
I
):
DC
injection
stop.
This
type
of
stop
cannot
be
used
with
certain
other
functions.
See
table
on
page
163
(1) Because, in this case, the detected fault does not trigger a stop, it is recommended to assign a relay or logic output to
its indication.
These parameters only appear if the corresponding function has been selected in another menu. When the parameters can
also be accessed and adjusted from w ithin the configuration menu for the corresponding function, their description is detailed
in these menus, on the pages indicated, to aid programming.
Parameter that can be modified during operation or w hen stopped.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > FLT- > TIT- / LFL-
*
