Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range Factory setting
USI
IL01
...
IL10
FbrM
SLS1
SLS2
SS11
SS12
StO1
StO2
SMS2
[+s peed around ref.]
(USI):
+ Speed around ref
[-spe e d around ref.]
(dSI):
- Speed around ref
[IL01]
(IL01):
Function blocks: Logical Input 1
...
[IL10]
(IL10):
Function blocks: Logical Input 10
[FB start]
(FbrM):
Function blocks: Run mode
[SLS ch.1]
(SLS1):
SLS safety function Channel 1
[SLS ch.2]
(SLS2):
SLS safety function Channel 2
[SS1 ch.1]
(SS11):
SS1 safety function Channel 1
[SS1 ch.2]
(SS12):
SS1 safety function Channel 2
[STO ch.1]
(St01):
STO safety function Channel 1
[STO ch.2]
(St02):
STO safety function Channel 2
[SM S ch.1]
(SMS1): SMS safety function Channel 1
[SM S ch.2]
(SMS2): SMS safety function Channel 2
Note:
Safety function channels are available for LI3-LI4 and LI5-LI6 only.
L1d
[LI1 On Delay]
0 to 200 ms 0 ms
This parameter is used to take account of the change of the logic input to state 1 w ith a delay that can be adjusted betw een 0
and 200 milliseconds, in order to filter out possible interference. The change to state 0 is taken into account w ithout delay.
to
L6-
All the logic inputs available on the drive are processed as in the example for LI1 above, up to LI6.
L5-
[LI5 CONFIGURATION]
Specific parameters for LI5 used as a pulse input.
PIA
[RP assignment]
Read-only parameter, cannot be configured.
It displays all the functions associated with the Pulse input in order to check, for example, for compatibility problems.
Identical to
[AI1 assignm ent]
(A11A) page 133.
PIL
[RP min value]
0 to 20.00 kHz 0 kHz
Pulse input scaling parameter of 0% in Hz * 10 unit.
PFr
[RP max value]
0 to 20.00 kHz 20.00 kHz
Pulse input scaling parameter of 100% in Hz * 10 unit.
PF
I
[RP filter]
0 to 1,000 ms 0 ms
I/O ext Pulse input cutoff time of the low -filter.
LA1-
LA2-
The 2 analog inputs AI1 and AI2 on the drive could be used as LI inputs and are processed as in the example for LI1 above.
These parameters only appear if the corresponding function has been selected in another menu. When the parameters can
also be accessed and adjusted from w ithin the configuration menu for the corresponding function, their description is detailed
in these menus, on the pages indicated, to aid programming.
To change the assignment of this parameter, press the ENT key for 2 s.
2 s
*
