Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range Factory setting
rSF
[Fault reset]
[No]
(nO)
nO
Detected faults are cleared manually w hen the assigned input or bit changes to 1, if the cause of the detected fault has
disappeared.
The STOP/RESET key on the graphic display terminal performs the same function.
Follow ing detected faults can be cleared manually :
ASF, brF, bLF, CnF,
COF,
dLF, EPF1, EPF2, FbES,
FCF2
,
InF9
,
InFA
,
In
Fb
,
LCF
,
LFF3
,
Ob
F
,
OHF
,
OLC
,
OL
F
,
OPF1
,
OPF2
,
OSF
,
OtFL
,
PHF
,
PtFL, SCF4, SCF5, SLF1, SLF2, SLF3,
SOF,
SPF, SSF,
tJF, tnF
and
ULF.
Note:
If [Reset restricted fault configuration] (HrFC) is set to [Yes] (YES), the additional follow ing detected fault can be
cleared manually: OCF
,
SCF1
,
SCF3. See page 252
[No]
(nO): Function inactive
[Ye s ]
(YES): Logical input LI1
[...]
(...): See the assignment conditions on page 153
rPA
[Product reset assig.]
[No]
(nO)
*
The Restart function performs a Fault Reset and then restarts the drive. During this Restart procedure, the drive goes through
the same steps as if it had been sw itched off and on again. Depending on the w iring and the configuration of the drive, this may
result in immediate and unanticipated operation. The Restart function can be assigned to a digital input.
WARNING
UNANTICIPATED EQUIPMENT OPERATION
The Restart function perform s a Fault Reset and res tarts the drive.
•
Verify that activating this function does not res ult in uns afe conditions.
Failure to follow these instructions can result in death, serious injury, or equipment damage
This
paramete r
can
only
be
modified
if
[3.1
ACCE S S
LEVE L ]
(
LAC
)
is
set
to
[Expe rt ]
(
EP
r
)
mode.
Drive reinitialization via logic input. Can be used to reset all detected faults without having to disconnect the drive from the power
supply. The drive is reinitialized on a rising edge (change from 0 to 1) of the assigned input. The drive can only be reinitialized
w hen locked.
To assign reinitialization, press and hold dow n the ENT key for 2 s.
[No]
(nO): Function inactive
[LI1]
(LI1):
Logical input LI1
...
[LI6]
(
LI6
):
Logical
input
LI6
[LAI1]
(LAI1):
Logical input AI1
[LAI2]
(LAI2):
Logical input AI2
[OL01]
(OL01): Function blocks: Logical Output 01
...
[OL10]
(OL10): Function blocks: Logical Output 10
nO
rP
[Product reset]
[No]
(nO)
*
The Restart function performs a Fault Reset and then restarts the drive. During this Restart procedure, the drive goes through
the same steps as if it had been sw itched off and on again. Depending on the w iring and the configuration of the drive, this may
result in immediate and unanticipated operation.
WARNING
UNANTICIPATED EQUIPMENT OPERATION
The Restart function perform s a Fault Reset and res tarts the drive.
•
Verify that activating this function does not res ult in uns afe conditions.
.
Failure to follow these instructions can result in death, serious injury, or equipment damage
This parameter can only be accessed if
[3.1 ACCESS LEVEL]
(LAC) is set to
[Expe rt]
(EPr) mode.
Drive reinitialization. Can be used to reset all detected faults w ithout having to disconnect the drive from the pow er supply.
[No]
(nO): Function inactive
[Ye s ]
(YES): Reinitialization. Press and hold dow n the ENT key for 2 s. The parameter changes back to
[No]
(nO)
automatically as soon as the operation is complete. The drive can only be reinitialized w hen locked.
nO
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > FLT- > RST-
