BLEMO ER24 Series - Menu; [Monit. Motor]

Monitoring Mode
(MOn)
50
Menu
Code Nam e / De s cription Unit
MOn-
[1.2 MONITORING]
AIU1

[Image input AIV1]
%
First virtual AI value.
This parameter is read-only. It enables you to display the speed reference applied to the motor.
FrH [Frequency ref.]
Hz
Frequency reference before ramp (signed value).
This parameter is read-only. It enables you to display the speed reference applied to the motor, regardless of w hich reference
channel has been selected.
StFr [Stator Frequency]
Hz
Displays the estimated stator frequency in Hz (signed value)
LFr [HMI Frequency ref.]
Hz
HMI frequency reference (signed value).
This parameter only appears if the function has been enabled. It is used to change the speed reference from the remote control.
ENT does not have to be pressed to enable a change of reference.
MF r
*

[Multiplying coeff.]
%
Multiply frequency variable.
Multiplying coefficient, can be accessed if [M ultiplier ref. -] (MA2,MA3) page 169 has been assigned.
MMF [Measured output fr.]
Hz
Measured motor frequency (signed value)
The measured motor speed is displayed if the speed monitoring card has been inserted. (VW3A3620)
rFr [Output frequency]
Hz
Estimated motor frequency (signed value).
FqS
*
[Pulse in. work. freq.]
Hz
Measured frequency of the "Pulse input" input (see page 265).
ULn [Mains voltage]
V
Main voltage (from DC bus).
Mains voltage based on DC bus measurement, motor running or stopped.
tHr [Motor thermal state]
%
Motor thermal state.
100% = Nominal thermal state, 118% = "OLF" threshold (motor overload).
tHd [Drv.thermal state]
%
Drive thermal state.
100% = Nominal thermal state, 118% = "OHF" threshold (drive overload).
MMO
-
[MONIT. MOTOR]
Spd [Motor speed]
rpm
Motor speed in rpm. (Estimated value)
UOP [Motor voltage]
V
Motor voltage. (Estimated value)
Op r [Motor power]
%
Output pow er monitoring (100% = nominal motor pow er, estimated value based on current measure).
Otr [Motor torque]
%
Output torque value (100% = nominal motor torque, estimated value based on current measure).
LCr [Motor current]
A
Estimated motor current. (Value measured)
Parameters described in this page can be accessed by:
DRI- > MON-
