BLEMO ER24 Series - [Monit. Pi]; [Monit. Power Time]

Monitoring Mode
(MOn)
62
Code Nam e / De s cription Unit
MOn
-
[1.2 MONITORING]
(continued)
M
p
I
-
*
[MONIT. PI]
PID management. Visible if [PID fe e dback as s .] (PIF) is not set to [No] (nO).
rPI

*
[Internal PID ref.]
Internal PID reference: As a process value.
rpE
*
[PID error]
PID error value.
rpF
*
[PID feedback]
PID feedback value.
rpC
*
[PID reference]
PID setpoint value via graphic display terminal.
rpO [PID Output]
Hz
PID output value w ith limitation.
MOn
-
[1.2 MONITORING]
(continued)
p
E
t
-
[MONIT. POWER TIME]
ApH [Consumption]
Wh, kWh, MWh
Energy consumption in Wh, kWh or MWh (accumulated consumption).
rt H [Run time]
s, min, h
Run elapsed time display (resetable) in seconds, minutes or hours (length of time the motor has been sw itched on).
ptH [Power on time]
s, min, h
Pow er elapsed time display in seconds, minutes or hours (length of time the drive has been sw itched on).
rpr

nO
APH
rtH
PtH
[Operating t. reset]
Reset of run elapsed time.
[No] (nO): Reset operation not in progress
[Reset kWh] (APH): Clear [Reset kWh] (APH)
[rst. runtim e] ( rt H ): Clear [rst. runt im e ] ( rtH )
[rst. P On t.] (PtH): Clear [rst. P On t.] (PtH)
MOn
-
[1.2 MONITORING]
(continued)
CnFS
nO
CnF0
CnF1
CnF2
[Config. active]
View of the active configuration.
[In progress] (nO): Transitory state (configuration changing)
[Config. n°0] (CnF0): Configuration 0 active
[Config. n°1] (CnF1): Configuration 1 active
[Config. n°2] (CnF2): Configuration 2 active
CFpS
*
nO
CFP1
CFP2
CFP3
[Utilised param. set]
Configuration parameter status (can be accessed if parameter sw itching has been enabled, see page 229).
[None ] (nO): Not assigned
[Se t N°1] (CFP1): Parameter set 1 active
[Se t N°2] (CFP2): Parameter set 2 active
[Se t N°3] (CFP3): Parameter set 3 active
Parameters described in this page can be accessed by:
DRI- > MON- > MPI-
