Configuration Mode (ConF)
Code Nam e / De s cription Adjus tment range Factory s e tting
EPL
[External fault mgt]
[Freew heel]
(YES)
nO
Type of stop in the event of an external fault.
[Ignore]
(nO): External fault ignored
[Freew heel]
(YES): Freew heel stop
[Per
STT]
(
Stt
):
Stop
according
to
configuration
of
[Type
of
stop]
(
Stt
)
page
173,
without
tripping.
In
this
case,
the
fault
relay does not open and the drive is ready to restart as soon as the detected fault disappears, according to the restart
condition s
of
the
active
command
channel
(for
example,
according
to
[2/3
wire
control]
(
tCC
)
and
[2
wire
type]
(
tCt
)
page
125
if control is via the terminals). Configuring an alarm for this detected fault is recommended (assigned to a logic
output, for example) in order to indicate the cause of the stop.
[fallback s pd]
(LFF): Change to fallback speed, maintained as long as the detected fault persists and the run command has
not been removed (1)
[Spd m aint.]
(rLS):
The drive maintains the speed being applied w hen the detected fault occurred, as long as the detected
fault is present and the run command has not been removed (1)
[Ram p s top]
(rMP): Stop on ramp
[Fast s top]
(FSt): Fast stop
[DC
injec t ion ]
(
dC
I
):
DC
injection
stop.
This
type
of
stop
cannot
be
used
with
certain
other
functions.
See
table
on
page
165
LFF
rLS
rMP
USb
[UnderV. fault mgt]
[Std fault]
(0)
0
Behavior of the drive in the event of an undervoltage.
[Std
fault]
(
0
):
The
drive
trips
and
the
external
fault
signal
is
triggered
(the
fault
relay
assigned
to
[No
drive
flt]
(
FL
t
)
will
be opened)
[Flt w o relay]
(1): The drive trips but the external fault signal is not triggered (the fault relay assigned to
[No drive flt]
remains closed)
[Alarm ]
(2): Alarm and fault relay remain closed. The alarm can be assigned to a logic output or a relay
1
2
UrES
[Mains voltage]
According to drive voltage
rating
According to drive voltage
rating
200
Rated voltage of the supply mains in V.
For ER24-…K/B:
[200V ac]
(200): 200 Volts AC
[220V ac]
(220): 220 Volts AC
[230V ac]
(230): 230 Volts AC
[240V ac]
(240): 240 Volts AC
For ER24-…/4K/B:
[380V ac]
(380): 380 Volts AC
[400V ac]
(400): 400 Volts AC
[440V ac]
(440): 440 Volts AC
[460V ac]
(4 0): 460 Volts AC
[500V ac]
(500): 500 Volts AC (factory setting)
380
USL
[Undervoltage level]
100 to 276 V According to drive rating
Undervoltage fault level setting in Volts. The factory setting is determined by the drive voltage rating.
US
t
[Undervolt. time out]
0.2 s to 999.9 s 0.2 s
Time delay for taking undervoltage detected fault into account.
StP
[UnderV. prevention]
[No]
(nO)
nO
Behavior in the event of the undervoltage prevention level being reached.
[No]
(nO): No action
[DC M aintain]
(MMS): This stop mode uses the inertia to maintain the DC bus voltage as long as possible
[Ram p s top]
(rMP): Stop follow ing an adjustable ramp
[M ax s top tim e ]
(StM)
[Lock -out]
(LnF): Lock (freew heel stop) w ithout error
tSM
*
[UnderV. restart tm]
1.0 s to 999.9 s 1.0 s
Time delay before authorizing the restart after a complete stop for
[Unde rV. prevention]
(StP) =
[Ram p stop]
(rMP), if
the voltage has returned to normal.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > FLT- > ETF-/USB-
