Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range Factory setting
FqF
nO
YES
[Frequency meter]
[No]
(nO)
Activation of the speed measurement function.
[No]
(nO): Function inactive. In this case, none of the function parameters can be accessed
[Ye s ]
(YES): Function active, assignment only possible if no other functions have been assigned to the "Pulse input" input
FqC
[Pulse scal. divisor]
1.0 to 100.0 1.0
Scaling factor for the "Pulse input" input (divisor). The frequency measured is displayed by means of the
[Puls e in. w ork . fre q.]
(FqS) parameter, page
50
.
FqA
nO
-
[Overspd. pulse thd.]
[No]
(nO)
Activation and adjustment of overspeed monitoring:
[Ove rspeed]
(SOF).
[No]
(nO): No overspeed monitoring
1 Hz to 20.00 k Hz
: Adjustment of the frequency tripping threshold on the "Pulse input" input divided by
[Puls e s cal. divis or]
(FqC).
tdS
[Pulse overspd delay]
0.0 s to 10.0 s 0.0 s
Time delay for taking overspeed detected fault into account.
Fd
t
nO
-
[Level fr. pulse ctrl]
[No]
(nO)
Activation and adjustment of monitoring for the Pulse input (speed feedback):
[Speed fdback loss]
(SPF).
[No]
(nO): No monitoring of speed feedback
0.1 Hz to 599 Hz
: Adjustment of the motor frequency threshold for tripping a speed feedback detected fault (difference between
the estimated frequency and the measured speed).
Fq
t
nO
-
[Pulse thd. wo Run]
[No]
(nO)
Activation and adjustment of brake monitoring:
[Brak e fe e dback ]
(brF).
If brake logic control
[Brak e as s ignm e nt]
(bLC) page 194 is not configured, this parameter is forced to
[No]
(nO).
[No]
(nO): No brake monitoring
1 Hz to 1,000 Hz
: Adjustment of the motor frequency threshold.
tqb
[Pulse wo Run delay]
0.0 s to 10.0 s 0.0 s
Time delay for taking brake monitoring into account.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > FLT- > FQF-
To Next Page
