Configuration Mode (ConF)
MULTIMOTORS / MULTICONFIGURATIONS
Motor or configuration switching [MULTIMOTORS/CONFIG.]
(MMC-)
The drive m ay contain up to 3 configurations , which can be saved us ing the
[FACTORY SETTINGS]
(FCS-) menu, page 81.
Each of thes e configurations can be activated rem otely, enabling adaptation to:
•
2 or 3 different m otors or m echanisms (m ultimotor m ode)
•
2 or 3 different configurations for a s ingle m otor (m ulticonfiguration m ode)
The two s witching m odes cannot be com bined.
Note:
The following conditions MUST be obs erved:
•
Switching m ay only take place when stopped (drive locked). If a switching request is s ent during operation,
it will not be executed until the next s top.
•
In the event of m otor switching, the following additional conditions apply:
- When the m otors are s witched, the power and control term inals concerned m ust als o be switched as
appropriate.
- The m axim um power of the drive m us t not be exceeded by any of the m otors .
•
All the configurations to be switched m ust be set and saved in advance in the s ame hardware configuration,
this being the definitive configuration (option and communication cards). Failure to follow this instruction can
cause the drive to lock on an
[Incorrect config.]
(CFF) s tate.
Menus and parameters switched in multimotor mode
•
[SETTINGS]
(
S
Et-
)
•
[MOTOR CONTROL]
(drC-)
•
[INPUTS / OUTPUTS CFG]
(
I
_O-
)
•
[COMMAN D ]
(
C
tL-
)
•
[APPLICATION FUNCT.]
(
Fun-
)
with the exception of the
[MULTIMOTORS/CONFIG.]
function (to be
configured once only)
•
[FAULT MANAGEMENT]
(FLt)
•
[MY MENU]
•
[USER CONFIG.]
: The nam e of the configuration s pecified by the us er in the
[FACTORY SETTINGS]
(FCS-) m enu
Menus and parameters switched in multiconfiguration mode
As in m ultim otor m ode, except for the m otor param eters that are com m on to the 3 configurations:
•
Rated current
•
Therm al current
•
Rated voltage
•
Rated frequency
•
Rated speed
•
Rated power
•
IR com pens ation
•
Slip com pensation
•
Synchronous m otor parameters
•
Type of therm al protection
•
Therm al state
•
The auto-tuning param eters and m otor parameters that can be acces sed in expert m ode
•
Type of m otor control
Note:
No other m enus or param eters can be switched.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > FUN- > MMC-
