Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range Factory setting
IdC
[DC inject. level 1]
0.1 to 1.41 In (2) 0.64 In (2)
*
NOTICE
OVERHEATING AND DAMAGE TO THE MOTOR
Verify that the connected m otor is properly rated for the DC injection current to be applied in term s of am ount
and tim e in order to avoid overheating and dam age to the m otor.
Failure to follow these instructions can result in equipment damage.
Level of DC injection braking current activated via logic input or selected as stop mode.
(1) (3)
tdI
[DC injection time 1]
0.1 to 30 s 0.5 s
*
NOTICE
OVERHEATING AND DAMAGE TO THE MOTOR
Verify that the connected m otor is properly rated for the DC injection current to be applied in term s of am ount
and tim e in order to avoid overheating and dam age to the m otor.
Failure to follow these instructions can result in equipment damage.
Maximum current injection time
[DC inject. le vel 1]
(IdC).
After this time, the injection current becomes
[DC
inject .
level
2]
(
I
dC2
).
(1) (3)
IdC2
[DC inject. level 2]
0.1 In (2) to
[DC inject. le vel 1]
(IdC)
0.5 In (2)
*
NOTICE
OVERHEATING AND DAMAGE TO THE MOTOR
Verify that the connected m otor is properly rated for the DC injection current to be applied in term s of am ount
and tim e in order to avoid overheating and dam age to the m otor.
Failure to follow these instructions can result in equipment damage.
Injection
current
activated
by
logic
input
or
selected
as
stop
mode,
once
period
of
time
[DC
injec t ion
time
1]
(
td
I
)
has
elapsed.
(1) (3)
