Code Nam e / De s cription Unit
Frequency signal image.
This menu is visible only on graphic display terminal.
Filtered customer pulse input frequency reference.
Follow ing parameters are visible on the graphic display terminal by pressing the ENT key on the parameter.
PIA
[RP assignment]
Pulse input assignment. If no functions have been assigned,
[No]
(nO) is displayed.
Identical to
[AI1 assignm ent]
(AI1A)
page 52.
PIL
[RP min value]
kHz
RP minimum value. Pulse input scaling parameter of 0%.
PFr
[RP max value]
kHz
RP maximum value Pulse input scaling parameter of 100%.
PF
I
[RP filter]
ms
Interference filtering pulse input cutoff time of the low -filter.
(continued)
For more details on Integrated Safety Functions, please refer to dedicated Safety manual.
StOS
IdLE
StO
FLt
[STO status]
Status of the Safe Torque Off safety function.
[Idle ]
(IdLE):
STO not in progress
[Safe s top]
(StO):
STO in progress
[Fault]
(FLt):
STO error detected
SLSS
nO
IdLE
WAIt
Strt
SS1
SLS
StO
FLt
[SLS status]
Status of the Safely-limited speed safety function.
[Not config.]
(nO): SLS not configured
[Idle ]
(IdLE):
SLS not in progress
[SLS w ait tim e]
(WAlt):
SLS w aiting for activation
[SLS
start]
(
Str
t
):
SLS
in
transient
state
[Safe ram p]
(SS1): SLS ramp in progress
[Spd lim ite d]
(SLS):
SLS speed limitation in progress
[Safe s top]
(StO):
SLS safe torque off request in progress
[Fault]
(FLt):
SLS error detected
SS1S
nO
SS1
FLt
[SS1 status]
Status of the Safe Stop 1 safety function.
[Not config.]
(nO): SS1 not configured
[Idle ]
(IdLE):
SS1 not in progress
[Safe ram p]
(SS1): SS1 ramp in progress
[Safe stop]
(StO): SS1 safe torque off request in progress
[Fault]
(FLt):
SS1 error detected
SMSS
nO
oFF
Fto
[SMS status]
Status of the Safe Maximum Speed safety function.
[Not Set]
(nO): SMS not set
[Activ e]
(
Off
):
SMS
active
[Interna l
Err.]
(
Fti
):
SMS
internal
error
[M ax Speed]
(Fto):
Maximum Speed reached
Parameters described in this page can be accessed by:
DRI- > MON- > IOM- > FSI-
