BLEMO ER24 Series - Page 51

Monitoring Mode (MOn)
53
Code Nam e / De s cription Unit
AIA
-
[ANALOG INPUTS IMAGE]
(continued)
Analog input functions.
AI3C
[AI3]
V
AI3 customer image: Value of analog input 3.
AI3A [AI3 assignment]
AI3 functions assignment. If no functions have been assigned, [No] (nO) is displayed.
Follow ing parameters are visible on the graphic display terminal by pressing the ENT key on the parameter.
Identical to [AI1 assignm ent] (AI1A) page 52.
CrL3 [AI3 min value]
mA
Current scaling parameter of 0%.
CrH3 [AI3 max value]
mA
Current scaling parameter of 100%.
AI3F [AI3 filter]
s
Interference filtering cutoff time of the low -filter.
IOM
-
[I/O MAP]
(continued)
AOA
-
[ANALOG OUTPUTS IMAGE]
Analog output functions.
Follow ing parameters are visible on the graphic display terminal by pressing the ENT key on the parameter.
AO1C

[AO1C]
AO1 customer image: Value of analog output 1.
AO1 [AO1 assignment]
AO1 functions assignment. If no functions have been assigned, [No] (nO) is displayed.
Identical to [AO1 assignm e nt] ( AO I ) page 144.
UOL1
*
[AO1 min Output]
V
Voltage scaling parameter of 0%. Can be accessed if [AO1 Type ] (AO1t) is set to [Voltage] (10U).
UOH1
*
[AO1 max Output]
V
Voltage scaling parameter of 100%. Can be accessed if [AO1 Type] (AO1t) is set to [Voltage] (10U).
AOL1
*
[AO1 min output]
mA
Current scaling parameter of 0%. Can be accessed if [AO1 Type] (AO1t) is set to [Curre nt] (0A).
AOH1
*
[AO1 max output]
mA
Current scaling parameter of 100%. Can be accessed if [AO1 Type] (AO1t) is set to [Curre nt] (0A).
ASL1 [Scaling AO1 max]
%
Minimum scaling value for AO1.
ASH1 [Scaling AO1 min]
%
Maximum scaling value for AO1.
AO1F [AO1 filter]
s
Cutoff time of the low -filter.
Parameters described in this page can be accessed by:
DRI- > MON- > IOM- > AIA- > AI3C
