Configuration Mode (ConF)
PID PRESET REFERENCES
Code Nam e / De s cription Adjustment range Factory setting
Function can be accessed if
[PID fe e dback as s .]
(PIF)
page 210 is assigned.
Pr2
nO
LI1
...
[2 preset PID ref.]
[No]
(nO)
If the assigned input or bit is at 0, the function is inactive.
If the assigned input or bit is at 1, the function is active.
[No]
(nO): Not assigned
[LI1]
(LI1):
Logical input LI1
[...]
(...): See the assignment conditions on page 153
Pr4
[4 preset PID ref.]
[No]
(nO)
Check that
[2 preset PID ref.]
(Pr2)
has been assigned before assigning this function.
Identical to
[2 pre s e t PID ref.]
(Pr2)
page 212.
If the assigned input or bit is at 0, the function is inactive.
If the assigned input or bit is at 1, the function is active.
rP2
*
(1)
[Preset ref. PID 2]
[M in PID refe rence]
(PIP1)
to
[M ax PID re fe rence ]
(PIP2)
(2)
300
This parameter can be accessed if
[2 pre s e t PID re f.2]
(Pr2)
is assigned.
rP3
*
(1)
[Preset ref. PID 3]
[M in PID refe rence]
(PIP1)
to
[M ax PID re fe rence ]
(PIP2)
(2)
600
This parameter can be accessed if
[3 pre s e t PID re f.]
(Pr3)
is assigned.
rP4
*
(1)
[Preset ref. PID 4]
[M in PID refe rence]
(PIP1)
to
[M ax PID re fe rence ]
(PIP2)
(2)
900
This parameter can be accessed if
[4 pre s e t PID re f.]
(Pr4)
is assigned.
(1)
The parameter can also be accessed in the
[SETTINGS]
(SEt-)
menu.
(2)
If a graphic display terminal is not in use, values greater than 9,999 w ill be displayed on the 4-digit display w ith a period
mark after the thousand digit, for example, 15.65 for 15,650.
These parameters only appear if the corresponding function has been selected in another menu. When the parameters can
also be accessed and adjusted from w ithin the configuration menu for the corresponding function, their description is detailed
in these menus, on the pages indicated, to aid programming.
Parameter that can be modified during operation or w hen stopped.
