Configuration Mode (ConF)
Deferred stop on thermal alarm
This function helps to prevent the drive stopping between two s teps of the proces s if the drive or m otor
overheats, by authorizing operation until the next s top. At the next s top, the drive is locked until the therm al
state falls back to a value, which undershoots the s et thres hold by 20%. Exam ple: A thres hold set at 80%
enables reactivation at 60%.
One therm al s tate threshold m ust be defined for the drive, and one therm al s tate threshold for the m otor(s ),
which will trigger the deferred s top.
Code Nam e / De s cription Adjus tment range Factory s e tting
SAt
nO
YES
[Thermal alarm stop]
[No]
(nO)
Thermal alarm stop function allow to set a custom alarm thermal level for the drive or the motor. When one of these levels is
reached, the drive trips in freewheel stop.
[No]
(nO): Function inactive (in this case, the follow ing parameters cannot be accessed)
[Ye s ]
(YES): Freewheel stop on drive or motor thermal alarm
tHA
[Drv therm. state al]
0 to 118% 100%
Thermal state threshold of the drive tripping the deferred stop.
tt
d
[Motor therm. level]
0 to 118% 100%
Thermal state threshold of the motor tripping the deferred stop.
tt
d2
[Motor2 therm. level]
0 to 118% 100%
Thermal state threshold of the motor 2 tripping the deferred stop.
tt
d3
[Motor3 therm. level]
0 to 118% 100%
Thermal state threshold of the motor 3 tripping the deferred stop.
EtF
nO
LI1
...
[External fault ass.]
[No]
(nO)
If the assigned bit is at 0, there is no external fault.
If the assigned bit is at 1, there is an external fault.
Logic can be configured via
[External fault config]
(LEt)
if a logic input has been assigned.
[No]
(nO): Function inactive
[LI1]
(LI1):
Logical input LI1
[...]
(...): See the assignment conditions on page 153
LE
t
*
LO
HIG
[External fault config]
[Active high]
(HIG)
Parameter can be accessed if the external fault has been assigned to a logic input. It defines the positive or negative logic of
the input assigned to the detected fault.
[Active low]
(LO): Triggering on falling edge (change from 1 to 0) of the assigned input
[Active high]
(HIG): Triggering on rising edge (change from 0 to 1) of the assigned input
