Introduction
The param eters can be acces sed when the drive is running or s topped.
Som e functions have numerous parameters. In order to clarify program ming and avoid having to s croll through
endles s parameters, thes e functions have been grouped in subm enus. Like m enus, s ubmenus are identified
by a das h after their code.
When the drive is running, the value dis played is one of the m onitoring parameters. By default, the value
dis played is the input frequency reference (
[Frequency ref.]
(FrH) param eter page 50).
While the value of the new m onitoring param eter required is being displayed, press a s econd tim e on the jog
dial key to display the units or pres s and hold down the jog dial (ENT) again (for 2 seconds) to confirm the
change of monitoring parameter and store it. From then on, it is the value of this param eter that will be
dis played during operation (even after powering down).
Unles s the new choice is confirm ed by pres s ing and holding down ENT again, the display will revert to the
previous param eter after powering down.
Note:
After the drive has been turned off or following a loss of s upply m ains , the param eter dis played is the
drive status (exam ple:
[Ready]
(rdY)). The selected param eter is dis played following a run com m and.
