POSITIONING BY SENSORS
This function is us ed for m anaging positioning using position sensors or lim it s witches linked to logic inputs or
using control word bits:
• Slowing down
• Stopping
The action logic for the inputs and bits can be configured on a rising edge (change from 0 to 1) or a falling edge
(change from 1 to 0). The exam ple below has been configured on a ris ing edge:
Forw ard run comman
Reverse run command
0
[Slow dow n forw ard]
0
[Stop FW limit sw .]
0
Speed
[Low speed]
(LSP)
0
The slowdown m ode and s top m ode can be configured.
The operation is identical for both directions of operation. Slowdown and stopping operate according to the
sam e logic, des cribed below.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > FUN- > LPO-
