Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range Factory setting
OCC
nO
LO1
r2
dO1
[Out. contactor ass.]
[No]
(nO)
Logic output or control relay.
[No]
(nO): Function not assigned (in this case, none of the function parameters can be accessed)
[LO1]
(LO1): Logical output LO1
[R2]
(r2):
Relay r2
[dO1]
(dO1): Analog output AO1 functioning as a logic output. Selection can be made if
[AO1 assignment]
(AO1) page 144
is set to
[No]
(nO)
rCA
nO
LI1
...
[Output contact. fdbk]
[No]
(nO)
The motor starts up w hen the assigned input or bit changes to 0.
[No]
(nO): Function inactive
[LI1]
(LI1):
Logical input LI1
[...]
(...): See the assignment conditions on page 153
dbS
*
[Delay to motor run]
0.05 to 60 s 0.15 s
Time delay for:
Motor control follow ing the sending of a run command
Output contactor state monitoring, if the feedback is assigned. If the contactor fails to close at the end of the set time, the drive
w ill lock in FCF2 mode.
This parameter can be accessed if
[Out. contactor as s .]
(OCC) is assigned or if
[Output contact. fdbk ]
(rCA) is assigned.
The time delay must be greater than the closing time of the output contactor.
dAS
*
[Delay to open cont.]
0 to 5.00 s 0.10 s
Time delay for output contactor opening command follow ing motor stop.
This parameter can be accessed if
[Output contact. fdbk ]
(rCA) is assigned.
The time delay must be greater than the opening time of the output contactor. If it is set to 0, the detected fault w ill not be
monitored.
If the contactor fails to open at the end of the set time, the drive w ill lock in FCF1 fault mode.
These parameters only appear if the corresponding function has been selected in another menu. When the parameters can
also be accessed and adjusted from w ithin the configuration menu for the corresponding function, their description is detailed
in these menus, on the pages indicated, to aid programming.
Parameter that can be modified during operation or w hen stopped.
*
