Introduction
Us e the reference m ode to m onitor and, if the reference channel is the analog input 1 (
[Ref.1 channel]
(Fr1)
page 154 s et to
[AI virtual 1]
(AIU1)),
adjus t the actual reference value by m odifying the analog input
voltage value.
If local control is enabled (
[Ref.1 channel]
(Fr1)
page 154 set to
[HMI]
(LCC)), the jog dial on the rem ote
dis play term inal or the Up/Down Navigation keys on the rem ote dis play term inal acts as a potentiom eter to
change the reference value up and down within the lim its pres et by other param eters (
[Low speed]
(LSP)
or
[High speed]
(HSP)).
There is no need to pres s the ENT key to confirm the change of the reference.
