Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range Factory setting
[TORQUE OR I LIM. DETECT]
SSb
[Trq/I limit. stop]
[Ignore ]
(nO)
nO
Behavior in the event of sw itching to torque or current limitation.
[Ignore]
(nO): Detected fault ignored
[Freew heel]
(YES): Freew heel stop
[Per
STT]
(
Stt
):
Stop
according
to
configuration
of
[Type
of
stop]
(
St
t
)
page
173,
without
fault
tripping.
In
this
case,
the
fault relay does not open and the drive is ready to restart as soon as the detected fault disappears, according to the restart
condition s
of
the
active
command
channel
(for
example,
according
to
[2/3
wire
control]
(
tCC
)
and
[2
wire
type]
(
tCt
)
page
125 if control is via the terminals). Configuring an alarm for this detected fault is recommended (assigned to a logic output, for
example) in order to indicate the cause of the stop
[fallback spd]
(LFF): Change to fallback speed, maintained as long as the detected fault persists and the run command has
not been removed (1)
[Spd m aint.]
(rLS):
The drive maintains the speed being applied w hen the detected fault occurred, as long as the detected
fault is present and the run command has not been removed (1)
[Ram p s top]
(rMP): Stop on ramp
[Fast s top]
(FSt): Fast stop
[DC injection]
(dCI):
DC injection stop. This type of stop cannot be used w ith certain other functions. See table on page 165
LFF
rLS
rMP
StO
[Trq/I limit. time out]
0 to 9,999 ms 1,000 ms
(If
[Trq/I lim it. stop]
(SSb) has been configured)
Time delay for taking SSF limitation into account.
(1) Because, in this case, the detected fault does not trigger a stop, it is recommended to assign a relay or logic output to
its indication.
Parameter that can be modified during operation or w hen stopped.
To change the assignment of this parameter, press the ENT key for 2 s.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > FLT- > TLD-
2 s
To Next Page
