Configuration Mode (ConF)
2ND CURRENT LIMITATION
Code Nam e / De s cription Adjustment range Factory s e tting
LC2
nO
LI1
...
[Current limit 2]
[No]
(nO)
If the assigned input or bit is at 0, the first current limitation is active.
If the assigned input or bit is at 1, the second current limitation is active.
[No]
(nO): Function inactive
[LI1]
(LI1):
Logical input LI1
[...]
(...): See the assignment conditions on page 153
CL2
*
[I Limit. 2 value]
0 to 1.5 In (1) 1.5 In (1)
NOTICE
OVERHEATING AND DAMAGE TO THE MOTOR
•
Verify that the m otor is properly rated for the maxim um current to be applied to the m otor.
•
Cons ider the duty cycle of the m otor and all factors of your application including derating requirements
in determ ining the current lim it.
Failure to follow these instructions can result in equipment damage.
Second current limitation.
This parameter can be accessed if
[Curre nt lim it 2]
(LC2) is not set to
[No]
(nO).
The adjustment range is limited to 1.5 In.
Note:
If the setting is less than 0.25 In, the drive may lock in
[Output Phase Loss]
(OPL) fault mode if this has been enabled
(see
[Output Phas e Loss]
(OPL) page 256). If it is less than the no-load motor current, the motor cannot run.
CL
I
*
[Current limitation]
0 to 1.5 In (1) 1.5 In (1)
NOTICE
OVERHEATING AND DAMAGE TO THE MOTOR
•
Verify that the m otor is properly rated for the maxim um current to be applied to the m otor.
•
Cons ider the duty cycle of the m otor and all factors of your application including derating requirements
in determ ining the current lim it.
Failure to follow these instructions can result in equipment damage.
First current limitation.
This parameter can be accessed if
[Curre nt lim it 2]
(LC2) is not set to
[No]
(nO).
The adjustment range is limited to 1.5 In.
Note:
If the setting is less than 0.25 In, the drive may lock in
[Output Phas e Loss]
(OPL) fault mode if this has been
enabled (see
[Output Phas e Loss]
(OPL) page 256). If it is less than the no-load motor current, the motor cannot run.
(1) In corresponds to the rated drive current indicated in the Installation manual and on the drive nameplate.
These parameters only appear if the corresponding function has been selected in another menu. When the parameters can
also be accessed and adjusted from w ithin the configuration menu for the corresponding function, their description is detailed
in these menus, on the pages indicated, to aid programming.
Parameter that can be modified during operation or w hen stopped.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > FUN- >CLI-
*
