Configuration Mode (ConF)
167
REFERENCE SWITCHING
Code Nam e / De s cription Adjus tment range Factory setting
FUn
-
[APPLICATION FUNCT.]
rEF
-
[REFERENCE SWITCH.]
rCb
[Ref 1B switching]
[ch1 active ]
(Fr1)
Fr1
See the diagrams on pages 147 and 148.
If the assigned input or bit is at 0,
[Ref.1 channe l]
(Fr1)
is active (see
[Ref.1 channel]
(Fr1)
page 154).
If the assigned input or bit is at 1,
[Ref.1B channel]
(Fr1b)
is active.
[Ref 1B sw itching]
(rCb)
is forced to
[ch1 active]
(Fr1)
if
[Profile ]
(CHCF) is set to
[Not s e par.]
(SIM)
w ith
[Ref.1 channel]
(Fr1)
assigned via the terminals (analog inputs, pulse input). See
[Ref.1 channel]
(Fr1)
page 154.
[ch1
active]
(
Frl
):
No
switching,
[Ref.1
channe l]
(
Fr1
)
active
[ch1B active]
(Fr1b):
No sw itching,
[Ref.1B channel]
(Fr1b)
active
[LI1]
(LI1):
Logical input LI1
[...]
(...): See the assignment conditions on page 153 (not
[Cd00]
(CdOO) to
[Cd15]
(Cd15)).
Fr1b
LI1
...
Fr1b
[Ref.1B channel]
[No]
(nO)
nO
[No]
(nO): Not assigned
[Al1]
(A11): Analog input A1
[Al2]
(A12): Analog input A2
[Al3]
(A13): Analog input A3
[HM I]
(LCC): Graphic display terminal or remote display terminal source
[M odbus ]
(Mdb): Integrated Modbus
[CANope n]
(CAn): Integrated CANopen®
[Com . card]
(nEt): Communication option board source
[RP]
(PI): Pulse input
[AI virtual 1]
(AIU1):
Virtual analog input 1 w ith the jog dial (only available if
[Profile ]
(CHCF) is not set to
[Not s e par.]
(SIM))
[OA01]
(OA01): Function blocks: Analog Output 01
...
[OA10]
(OA10): Function blocks: Analog Output 10
A11
A12
A13
LCC
Mdb
CAn
nEt
PI
AIU1
OA01
...
OA10
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > FUN- > REF-
