Configuration Mode (ConF)
AUTO DC INJECTION
Code Nam e / De s cription Adjustment range Factory s e tting
AdC
[Auto DC injection]
[Ye s ]
(YES)
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH
If the param eter
[Auto DC injection]
(AdC) is set to
[Continuous]
(Ct), DC injection is always active, even
if the motor does not run.
•
Verify that us ing this s etting does not res ult in uns afe conditions.
Failure to follow these instructions will result in death or serious injury.
WARNING
UNINTENDED MOVEMENT
•
Do not us e DC injection to generate holding torque when the m otor is at a stands till.
•
Us e a holding brake to keep the m otor in the stands till pos ition.
Failure to follow these instructions can result in death, serious injury, or equipment damage.
Automatic current injection on stopping (at the end of the ramp).
Note:
There is an interlock betw een this function and
[M otor fluxing]
(FLU) page 95. If
[M otor fluxing]
(FLU) is set to
[Continuous]
(FCt),
[Auto DC inje ction]
(AdC) must be
[No]
(nO).
Note: [Auto DC inje ction]
(AdC) is set to
[No]
(nO) w hen
[M otor control type]
(Ctt) page 105 is set to
[Sync. m ot.]
(SYn).
[Auto DC inje ction]
(AdC) is forced to
[No]
(nO) w hen
[Brake as signment]
(bLC) page 194 is not set to
[No]
(nO). This
parameter gives rise to the injection of current even if a run command has not been sent. It can be accessed with the drive
running.
[No]
(nO): No injection
[Ye s ]
(YES): Adjustable injection time
[Continuous]
(Ct): Continuous standstill injection
2 s
nO
SdC1
[Auto DC inj. level 1]
0 to 1.2 In (2) 0.7 In (2)
*
NOTICE
OVERHEATING AND DAMAGE TO THE MOTOR
Verify that the connected m otor is properly rated for the DC injection current to be applied in term s of am ount
and tim e in order to avoid overheating and dam age to the m otor.
Failure to follow these instructions can result in equipment damage.
Level of standstill DC injection current
[Auto DC inje ction]
(AdC) is not
[No]
(nO).
(1)
tdC1
[Auto DC inj. time 1]
0.1 to 30 s 0.5 s
*
NOTICE
OVERHEATING AND DAMAGE TO THE MOTOR
Verify that the connected m otor is properly rated for the DC injection current to be applied in term s of am ount
and tim e in order to avoid overheating and dam age to the m otor.
Failure to follow these instructions can result in equipment damage.
Standstill injection time. This parameter can be accessed if
[Auto DC inje ction]
(AdC) is not set to
[No]
(nO).
If
[M otor control type]
(Ctt) page 105 is set to
[Sync. m ot.]
(SYn), this time corresponds to the zero speed maintenance
time.
(1)
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > FUN- > ADC-
