Code Nam e / De s cription Adjustment range Factory setting
drI-
rEF-
[1.1 SPEED REFERENCE]
Displayed parameters depend on drive settings.
AIU1
*
(
1
)
[Image input AIV1]
0 to 100% of HSP-LSP 0%
First virtual AI value.
This parameter allow s to modify the frequency reference with the embedded jog dial.
LFr
*
(
1
)
[HMI Frequency ref.]
-599 to +599 Hz 0 Hz
HMI frequency reference (signed value).
This parameter allow s to modify the frequency reference with the remote HMI.
MF
r
*
[Multiplying coeff.]
0 to 100% 100%
Multiply frequency variable.
Multiplying coefficient, can be accessed if
[M ultiplier ref.-]
(MA2,MA3) page 169 has been assigned to the graphic terminal.
rPI
*
(
1
)
[Internal PID ref.]
0 to 32,767 150
PID: Internal reference PI.
This parameter allow s to modify the PID internal reference with the jog dial.
Internal PID reference is visible if
[PID feedback]
(PIF)
is not set to
[No]
(nO).
FrH
*
[Frequency ref.]
-599 to +599 Hz
-
Frequency reference before ramp (signed value).
Actual frequency reference applied to the motor regardless of which reference channel has been selected. This parameter is in
read-only mode.
Frequency reference is visible if the command channel is not HMI or virtual AI.
rPC
*
[PID reference]
0 to 65,535
-
PID: Setpoint value.
PID reference is visible if
[PID fe e dback ]
(PIF)
is not set to
[No]
(nO).
(1) It is not necessary to press the ENT key to confirm the modification of the reference.
These parameters only appear if the corresponding function has been selected in another menu. When the parameters can
also be accessed and adjusted from w ithin the configuration menu for the corresponding function, their description is detailed
in these menus, on the pages indicated, to aid programming.
Parameter that can be modified during operation or w hen stopped.
Parameters described in this page can be accessed by:
DRI- > REF-
*
