Monitoring Mode (MOn)
55
Code Nam e / De s cription Unit
GdLS [GDL status]
Status of the Guard Door Locking safety function.
nO
[Not Set] (nO): GDL not set
oFF
[
I
nac
t
ive
]
(
Off
)
:
GDL
inactive
Std
[Short De lay]
(Std)
:
Short Delay In Progress
LGD
[Long Delay]
(LGd)
: Long Delay In
Progress
oN
[Active ]
(LGd)
: GDL active
LFt
[Internal Err.]
(LGd)
: GDL internal error
SFFE [Safety fault reg.]
Safety function error register.
Bit0 = 1: Logic inputs debounce time-out (verify value of debounce time LIDT according to the application)
Bit1 Reserved
Bit2 = 1: Motor speed sign has changed during SS1 ramp
Bit3 = 1: Motor speed has reached the frequency limit threshold during SS1 ramp.
Bit4: Reserved
Bit5: Reserved
Bit6 = 1: Motor speed sign has changed during SLS limitation
Bit7 = 1: Motor speed has reached the frequency limit threshold during SS1 ramp.
Bit8: Reserved
Bit9: Reserved
Bit10: Reserved
Bit11: Reserved
Bit12: Reserved
Bit13 = 1: Not possible to measure the motor speed (verify the motor w iring connection)
Bit14 = 1: Motor ground short-circuit detected (verify the motor w iring connection)
Bit15 = 1: Motor phase to phase short-circuit detected (verify the motor w iring connection)
MOn
-
[1.2 MONITORING]
(continued)
MFb
-
[MONIT. FUN. BLOCKS]
For more details on Function Blocks, please refer to dedicated Function Blocks manual.
FbS t [FB status]
Function Block Status.
IdLE
[Idle ] (IdLE): Idle state
CHEC
[Che ck prog.]
(CHEC)
: Check program state
StOP
[Stop]
(StOP)
:
STOP state
InIt
[
I
nit
]
(
InIt
)
:
Initializatio n
state
rUn
[Run]
(rUn)
:
RUN state
Err
[Error]
(Err)
:
Error state
FbF t [FB fault]
Status of the function blocks execution.
nO
[No] (nO): No error detected
Int
[
I
nter
na
l
]
(
Int
)
:
In
t
ernal
er
ror
det
e
c
ted
bIn
[Binary file ]
(bIn)
:
Binary error detected
InP
[Intern para.]
(InP)
:
Internal parameter error detected
PAr
[Para. RW]
(PAr)
: Parameter access error detected
CAL
[Calculation]
(CAL)
: Calculation error detected
tOAU
[TO AUX]
(tOAU)
: TimeOut AUX task
tOPP
[TO synch]
(tOPP)
:
TimeOut in PRE/POST task
AdL
[Bad ADLC]
(AdL)
: ADLC w ith bad parameter
In
[
I
np
ut
ass
i
gn.
]
(
In
)
:
Input
not
configure d
FbI
-
[FB IDENTIFICATION]
bUEr
*
[Program version]
Program user version. Can be accessed if [FB status ] (FbSt) is not set to [Idle ] (IdLE).
bnS
*
[Program size]
Program file size. Can be accessed if [FB status ] (FbSt) is not set to [Idle ] (IdLE).
Parameters described in this page can be accessed by:
DRI- > MON- > SAF-
