Configuration Mode (ConF)
129
Configuration of analog inputs and Pulse input
The m inim um and m axim um input values (in volts, m A, etc.) are converted to % in order to adapt the
references to the application.
Minimum and maximum input values:
The m inim um value corres ponds to a reference of 0% and the m axim um value to a reference of 100%. The
m inim um value m ay be greater than the m axim um value:
Reference
100%
Current or voltage
or pulse input
0%
[M in value]
(CrLx or
[M ax value]
(CrHx or
20 mA or
10 V or
ULx or PIL)
UHx or PFr)
20.00 kHz
Reference
100%
Current or voltage
or pulse input
0%
[M ax value]
(CrHx or
UHx or PFr)
[M in value ]
(CrLx or
ULx or PIL)
20 mA or
10 V or
20.00 kHz
For +/- bidirectional inputs, the m in. and m ax. are relative to the abs olute value, for exam ple +/- 2 to 8 V.
