Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range Factory setting
This function can be accessed if reference channel
[Ref.2 channe l]
(Fr2)
is set to
[+/-Spe e d]
(UPdt),
see page 155.
Note:
This function cannot be used w ith certain other functions. Follow the instructions on page 163 .
USP
nO
LI1
...
[+ speed assignment]
[No]
(nO)
Function active if the assigned input or bit is at 1.
[No]
(nO): Not assigned
[LI1]
(LI1):
Logical input LI1
[...]
(...): See the assignment conditions on page 153
dSP
[-Speed assignment]
[No]
(nO)
See the assignment conditions on page 153
Function active if the assigned input or bit is at 1.
Str
*
nO
rAM
EEP
[Reference saved]
[No]
(nO)
Associated with the "+/- speed" function, this parameter can be used to save the reference:
-
When the run commands disappear (saved to RAM).
-
When the supply mains or the run commands disappear (saved to EEPROM).
Therefore, the next time the drive starts up, the speed reference is the last reference saved.
[No]
(nO): No save (the next time the drive starts up, the speed reference is
[Low speed]
(LSP), see page 87)
[RAM ]
(rAM): Saved in RAM
[EEprom ]
(EEP): Saved in EEPROM
These parameters only appear if the corresponding function has been selected in another menu. When the parameters can
also be accessed and adjusted from w ithin the configuration menu for the corresponding function, their description is detailed
in these menus, on the pages indicated, to aid programming.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > FUN- > UPD-
*
