Configuration Mode (ConF)
187
Code Nam e / De s cription Adjustment range Factory setting
FUn
-
[APPLICATION FUNCT.]
(continued)
SrE
-
[+/
-
SPEED AROUND REF.]
The function can be accessed for reference channel [Ref.1 channel] (Fr1).
Note: This function cannot be used w ith certain other functions. Follow the instructions on page 166.
US I
nO
LI1
...
[+ speed assignment]
[No] (nO)
No] (nO): Not assigned
[LI1] (LI1): Logical input LI1
[...] (...): See the assignment conditions on page 153
dS I [-Speed assignment]
[No] (nO)
See the assignment conditions on page 153
Function active if the assigned input or bit is at 1.
SrP
*

[+/-Speed limitation]
0 to 50% 10%
This parameter limits the variation range w ith +/- speed as a % of the reference. The ramps used in this function are
[Accele ration 2] (AC2) and [Dece leration 2] (dE2).
This parameter can be accessed if +/- speed is assigned.
AC2
*

(1)
[Acceleration 2]
0.00 to 6,000 s (2) 5.00 s
Time to accelerate from 0 to the [Rated m otor freq.] (FrS). To have repeatability in ramps, the value of this parameter must
be set according to the possibility of the application.
This parameter can be accessed if [+/- spe e d] (tUd) is assigned.
dE2
*

(1)
[Deceleration 2]
0.00 to 6,000 s (2) 5.00 s
Time to decelerate from the [Rated m otor freq.] (FrS) to 0. To have repeatability in ramps, the value of this parameter must
be set according to the possibility of the application.
This parameter can be accessed if [+/- spe e d] (tUd) is assigned.
(1) The parameter can also be accessed in the [SETTINGS] (SEt-) menu.
(2) Range 0.01 to 99.99 s or 0.1 to 999.9 s or 1 to 6,000 s according to [Ram p increment] (Inr) page 170.
These parameters only appear if the corresponding function has been selected in another menu. When the parameters can
also be accessed and adjusted from w ithin the configuration menu for the corresponding function, their description is detailed
in these menus, on the pages indicated, to aid programming.
Parameter that can be modified during operation or w hen stopped.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > FUN- > SRE-
*


