Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range Factory setting
ASt
[Angle setting type]
[PSIO align.]
(PSIO)
*
Mode
for
measurin g
the
phase-s hift
angle.
Visible
only
if
[Mot o r
control
type]
(
Ctt
)
is
set
to
[Sync.
mot.]
(
SYn
).
[PSI align]
(PSI) and
[PSIO align]
(PSIO) are w orking for all type of synchronous motors.
[SPM align]
(SPMA) and
[IPM align]
(IPMA) increase performances depending on the type of synchronous motor.
[IPM align]
(IPMA): Alignment for IPM motor. Alignment mode for Interior-buried Permanent Magnet motor (usually, this kind
of motor has a high saliency level). It uses high frequency injection, w hich is less noisy than standard alignment mode.
[SPM align]
(SPMA): Alignment for SPM motor. Mode for Surface-mounted Permanent Magnet motor (usually, this kind of
motor has a medium or low saliency level). It uses high frequency injection, w hich is less noisy than standard alignment mode.
[PSI align]
(PSI): Pulse signal injection. Standard alignment mode by pulse signal injection.
[PSIO align]
(PSIO): Pulse signal injection - Optimized. Standard optimized alignment mode by pulse signal injection. The
phase-shift angle measurement time is reduced after the first run order or tune operation, even if the drive has been turned off.
[No align]
(nO): No alignment
IPMA
PSI
nO
(1)
The parameter can also be accessed in the
[SETTINGS]
(SEt-)
menu.
These parameters only appear if the corresponding function has been selected in another menu. When the parameters can
also be accessed and adjusted from w ithin the configuration menu for the corresponding function, their description is detailed
in these menus, on the pages indicated, to aid programming.
Parameter that can be modified during operation or w hen stopped.
To change the assignment of this parameter, press the ENT key for 2 s.
2 s
*
