Configuration Mode (ConF)
USL
*
[Undervoltage level]
Undervoltage fault level setting in Volts.
100 to 276 Vac According to drive
rating
Visible if
[3.1 ACCESS LEVEL]
(LAC) is set to
[Expe rt]
(Epr),
[DC-Bus chaining]
(dCCM) above is set to
[No]
(
nO
)
[M ains voltage ]
(UrES) is not set to
[Le xium ]
(LHM).
The factory setting is determined by the drive voltage rating :
-
For ER24-…K/B
: 141 Vac
-
For ER24-…/4K/B
: 276 Vac
The adjustment range is determined by the
[M ains voltage ]
(UrES) value.
See
[Unde rvoltage level]
(USL) in the Programming Manual (DRI- > CONF > FULL > FLT- > USB-).
Ubr
*
[Braking level]
Braking transistor command level.
335 to 820 Vdc According to drive
rating
Visible if
[3.1 ACCESS LEVEL]
(LAC) is set to
[Expe rt]
(Epr)
and
[DC-Bus chaining]
(dCCM) above is set to
[No]
(nO).
The factory setting is determined by the drive voltage rating :
-
For ER24-…K/B: 395 Vdc
-
For ER24-…/$K/B: 820 Vdc
The adjustment range is determined by the
[M ains voltage ]
(UrES) value.
See
[Brak ing level]
(Ubr)
in the Programming Manual (DRI- > CONF > FULL > DRC-).
Parameter that can be modified during operation or w hen stopped.
Thes e param eters only appear if the corres ponding function has been s elected in another m enu. When the parameters
can als o be acces sed and adjusted from within the configuration m enu for the corresponding function, their description
is detailed in these m enus , on the pages indicated, to aid program m ing
.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > DCC-
*
