Monitoring Mode
(MOn)
72
Code Nam e / De s cription Unit
SF05 [SAFF Subcode 5] (1)
Safety fault subregister 05
[Safe Stop 1] SS1 detected error register
Bit0 = 1 : State machine detected error
Bit1 = 1 : Motor speed sign changed during stop
Bit2 = 1 : Motor speed reached trigger area
Bit3 = 1 : Theoretical motor speed corrupted
Bit4 = 1 : Unauthorized configuration
Bit5 = 1 : Theoretical motor speed computation detected error
Bit6 : Reserved
Bit7 = 1 : Speed sign check: consistency detected error
Bit8 = 1 : Internal SS1 request corrupted
Bit9 : Reserved
Bit10 : Reserved
Bit11 : Reserved
Bit12 : Reserved
Bit13 : Reserved
Bit14 : Reserved
Bit15 : Reserved
SF0
[SAFF Subcode 6] (1)
Safety fault subregister 06
[Safely Limited Speed] SLS detected error register
Bit0 = 1 : State machine error register
Bit1 = 1 : Motor speed sign changed during limitation
Bit2 = 1 : Motor speed has reached the frequency limit threshold
Bit3 = 1 : Data corruption
Bit4 : Reserved
Bit5 : Reserved
Bit6 : Reserved
Bit7 : Reserved
Bit8 : Reserved
Bit9 : Reserved
Bit10 : Reserved
Bit11 : Reserved
Bit12 : Reserved
Bit13 : Reserved
Bit14 : Reserved
Bit15 : Reserved
SF07 [SAFF Subcode 7] (1)
Safety fault subregister 07
Application Watchdog Management detected error register
Bit0 : Reserved
Bit1 : Reserved
Bit2 : Reserved
Bit3 : Reserved
Bit4 : Reserved
Bit5 : Reserved
Bit6 : Reserved
Bit7 : Reserved
Bit8 : Reserved
Bit9 : Reserved
Bit10 : Reserved
Bit11 : Reserved
Bit12 : Reserved
Bit13 : Reserved
Bit14 : Reserved
Bit15 : Reserved
(1) Hexadecimal values are displayed on the Graphic display terminal
Example:
SFFE = 0x0008 in Hexadecimal
SFFE = Bit 3
