10. Tighten the clamping screw until a sufficiently high pre-ten-
sion on the Multi Disc has been achieved or pressurize the
clamping unit in the version with pneumatic adjustment.
— If necessary, correct the pre-tension as described in
Ä
Chapter 5.1 “Commissioning” on page 95.
Adjust the clearance!
— Adjust the slotted nut [N] in such a way that the distance between the Multi
Disc and the press channel (or filter press channel in the case of the HP ver-
sion) is very small but the plates do not rub against each other.
11.
Install the counter bearing cover according to
Ä
Chapter
6.3.4 “Changing the Multi Disc plate” on page 146.
Maintenance and repairs
BA-RC40_EN, 17.01.2024www.boerger.de / www.boerger.com152
