— Secure the Börger machine against unauthorized or uncon-
trolled reactivation as described in
Ä
Chapter 2.7 “Securing the
machine against restart” on page 26
— To the extent necessary, amply secure the surrounding area
when performing maintenance. Cordon off the working area
with a red and white safety chain and a warning sign.
— Relieve the pressure in the Börger machine according to
Ä
Chapter 6.1.2 “Pressure relief” on page 114.
— Clean the interior of the Börger machine as described in
Ä
Chapter 6.1.3 “Internal cleaning” on page 116.
— Loosen the clamping screw of the clamping unit as described in
Ä
Chapter 6.3.2 “Removing/repairing the clamping unit”
on page 131, or depressurize the clamping unit in the version
with pneumatic adjustment.
— Disassemble the clamping unit as described in
Ä
Chapter 6.3.2
“Removing/repairing the clamping unit” on page 131.
— Disassemble the Multi Disc as described in
Ä
Chapter 6.3.4
“Changing the Multi Disc plate” on page 146.
— Disassemble the filter press channel as described in
Ä
Chapter
6.3.5 “Changing the filter press channel” on page 150.
— Remove the brush auger as described in
Ä
Chapter 6.3.7
“Replacing the brush auger” on page 157.
1. Longer thick matter plug:
Screw together the two auger adapters (3, 5) in the direction
of the Multi Disc.
2. Shorter thick matter plug:
Screw together the two auger adapters (3, 5) in the direction
of the drive.
3.
Install the brush auger as described in
Ä
Chapter 6.3.7
“Replacing the brush auger” on page 157.
4.
Install the filter press channel as described in
Ä
Chapter
6.3.5 “Changing the filter press channel” on page 150.
5.
Install the Multi Disc as described in
Ä
Chapter 6.3.4
“Changing the Multi Disc plate” on page 146.
Maintenance and repairs
BA-RC40_EN, 17.01.2024 www.boerger.de / www.boerger.com 165
