The recommended size of the service spaces for maintenance
and repair work is:
Service space dimensions
Dimensions approx. [m] approx. [ft]
RC 40 RC 40 HP RC 40 RC 40 HP
A 1.0 1.0 3.3 3.3
B 2.0 2.0 6.6 6.6
NOTE!
Service space
Ensure that the service spaces at the compactor and the adjust-
ment units are accessible with a telescopic loader or similar.
Ensure that there is sufficient circulation of air around the drive;
see the drive manufacturer's operating manual.
Transportation, Storage and Installation
BA-RC40_EN, 17.01.2024www.boerger.de / www.boerger.com76
