Modular Fire Panel Installation | en 145
Bosch Sicherheitssysteme GmbH System Description F.01U.028.089 | 8.0 | 2011.07
Figure 4.100 FMR-5000 wiring with BCM
FMR-5000
FPA-5000
FPP-5000
FMR-5000
24V (2,8 A) DC2
24V (2,8 A) DC1
-AC FAULT IN2
-BAT FAULT IN1
MAIN POWER
MAIN POWER
TROUBLE
TROUBLE
TROUBLE
BATTERY 1
BATTERY 2
BCM-0000-B
24V (2,8 A) DC2
24V (2,8 A) DC1
MAIN POWER
MAIN POWER
TROUBLE
TROUBLE
TROUBLE
BATTERY 1
BATTER
Y 2
BCM-0000-B
1
2
1
2
NOTICE!
The value 2.8 A must be set in the configuration window of the BCM-0000-B in the panel's
programming software.
