Bouffalo Lab BL702 - Page 102

BL702/704/706 Reference Manual
Bits
Name Type Reset Description
16 MBBP R/W 1’b0 micboost amp bypass
1’b0: not bypass
1’b1: bypass
15 MPEN R/W 1’b0 micpga enable
1’b0: micpga disable
1’b1: miapga enable
14 MBEN R/W 1’b0 enable micbias
1’b0: micbias power down
1’b1: miabias power on
13 NGGR R/W 1’b0 set negative input of adc to ground
1’b0: disable
1’b1: enable
12:8 POSSEL R/W 5’hf select adc positive input in none-scan mode
5’h0 gpip_ch[0]
5’h1 gpip_ch[1]
5’h2 gpip_ch[2]
5’h3 gpip_ch[3]
5’h4 gpip_ch[4]
5’h5 gpip_ch[5]
5’h6 gpip_ch[6]
5’h7 gpip_ch[7]
5’h8 gpip_ch[8]
5’h9 gpip_ch[9]
5’h10 gpip_ch[10]
5’h11 gpip_ch[11]
5’h12 daca
5’h13 dacb
5’h14 temp_p
5’h16 vref
5’h18 vbat/2
5’h23-31 avss
BL702/704/706 Reference Manual 102/ 375
