BL702/704/706 Reference Manual

Bits

Name Type Reset Description

1 GP36SMT R/W 1 GPIO SMT Control

0 GP36IE R/W 1 GPIO Input Enable

3.3.37 GPIO_CFGCTL30

Address：0x40000180

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

GP31

I

GP30

I

GP29

I

GP28

I

GP27

I

GP26

I

GP25

I

GP24

I

GP23

I

GP22

I

GP21

I

GP20

I

GP19

I

GP18

I

GP17

I

GP16

I

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

GP15

I

GP14

I

GP13

I

GP12

I

GP11

I

GP10

I

GP9

I

GP8

I

GP7

I

GP6

I

GP5

I

GP4

I

GP3

I

GP2

I

GP1

I

GP0

I

Bits

Name Type Reset Description

31 GP31I R 0 Register Controlled GPIO Input value

30 GP30I R 0 Register Controlled GPIO Input value

29 GP29I R 0 Register Controlled GPIO Input value

28 GP28I R 0 Register Controlled GPIO Input value

27 GP27I R 0 Register Controlled GPIO Input value

26 GP26I R 0 Register Controlled GPIO Input value

25 GP25I R 0 Register Controlled GPIO Input value

24 GP24I R 0 Register Controlled GPIO Input value

23 GP23I R 0 Register Controlled GPIO Input value

22 GP22I R 0 Register Controlled GPIO Input value

21 GP21I R 0 Register Controlled GPIO Input value

20 GP20I R 0 Register Controlled GPIO Input value

19 GP19I R 0 Register Controlled GPIO Input value

18 GP18I R 0 Register Controlled GPIO Input value

17 GP17I R 0 Register Controlled GPIO Input value

16 GP16I R 0 Register Controlled GPIO Input value

15 GP15I R 0 Register Controlled GPIO Input value

14 GP14I R 0 Register Controlled GPIO Input value

13 GP13I R 0 Register Controlled GPIO Input value

BL702/704/706 Reference Manual 71/ 375

@2021 Bouffalo Lab
