BL702/704/706 Reference Manual
3.3.30 GPIO_CFGCTL12
Address：0x40000130
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD GP25FUNC RSVD GP25
PD
GP25
PU
GP25DRV GP25
SMT
GP25
IE
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD GP24FUNC RSVD GP24
PD
GP24
PU
GP24DRV GP24
SMT
GP24
IE
Bits
Name Type Reset Description
31:29 RSVD
28:24 GP25FUNC R/W 5’hB GPIO Function Select (Default : SWGPIO )
23:22 RSVD
21 GP25PD R/W 0 GPIO Pull Down Control
20 GP25PU R/W 0 GPIO Pull Up Control
19:18 GP25DRV R/W 0 GPIO Driving Control
17 GP25SMT R/W 1 GPIO SMT Control
16 GP25IE R/W 1 GPIO Input Enable
15:13 RSVD
12:8 GP24FUNC R/W 5’hB GPIO Function Select (Default : SWGPIO )
7:6 RSVD
5 GP24PD R/W 1 GPIO Pull Down Control
4 GP24PU R/W 0 GPIO Pull Up Control
3:2 GP24DRV R/W 0 GPIO Driving Control
1 GP24SMT R/W 1 GPIO SMT Control
0 GP24IE R/W 1 GPIO Input Enable
