BL702/704/706 Reference Manual
3.3.23 GPIO_CFGCTL5
Address：0x40000114
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD GP11FUNC RSVD GP11
PD
GP11
PU
GP11DRV GP11
SMT
GP11
IE
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD GP10FUNC RSVD GP10
PD
GP10
PU
GP10DRV GP10
SMT
GP10
IE
Bits
Name Type Reset Description
31:29 RSVD
28:24 GP11FUNC R/W 5’hB GPIO Function Select (Default : SWGPIO )
23:22 RSVD
21 GP11PD R/W 0 GPIO Pull Down Control
20 GP11PU R/W 0 GPIO Pull Up Control
19:18 GP11DRV R/W 0 GPIO Driving Control
17 GP11SMT R/W 1 GPIO SMT Control(Useless, IE depend on reg_aon_pad_-
ie_smt[2] : 0x4000F014[10])
16 GP11IE R/W 1 GPIO Input Enable (Useless, IE depend on reg_aon_pad_-
ie_smt[2] : 0x4000F014[10])
15:13 RSVD
12:8 GP10FUNC R/W 5’hB GPIO Function Select (Default : SWGPIO )
7:6 RSVD
5 GP10PD R/W 0 GPIO Pull Down Control
4 GP10PU R/W 0 GPIO Pull Up Control
3:2 GP10DRV R/W 0 GPIO Driving Control
1 GP10SMT R/W 1 GPIO SMT Control(Useless, IE depend on reg_aon_pad_-
ie_smt[1] : 0x4000F014[9])
0 GP10IE R/W 1 GPIO Input Enable (Useless, IE depend on reg_aon_pad_-
ie_smt[1] : 0x4000F014[9])
BL702/704/706 Reference Manual 58/ 375
