BL702/704/706 Reference Manual
Bits
Name Type Reset Description
31:16 CGENS1A R/W 16’h9B23 [0] uart0 clock ungate enable
[1] uart1 clock ungate enable
[2] spi clock ungate enable
[3] i2c clock ungate enable
[4] pwm clock ungate enable
[5] timer clock ungate enable
[6] ir_remote clock ungate enable
[7] checksum clock ungate enable
[8] qdec0 clock ungate enable
[9] qdec1 clock ungate enable
[10] i2s and qdec2 clock ungate enable
[11] kys clock ungate enable
[12] usb clock ungate enable
15:0 CGENS1 R/W 16’hCFFF [2] gpip (gpadc, gpdac) clock ungate enable
[3] sec_dbg clock ungate enable
[4] sec_eng clock ungate enable
[5] tzc clock ungate enable
[7] ef_ctrl clock ungate enable
[11] sf_ctrl clock ungate enable
[12] DMA clock ungate enable
[13] emac clock ungate enable
3.3.10 bmx_cfg1
Address：0x40000050
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD ERR
EN
RSVD ARBMODE TIMOUTEN
Bits
Name Type Reset Description
31:9 RSVD
8 ERREN R/W 0 Bus error response enable
7:6 RSVD
5:4 ARBMODE R/W 0 Bus arbiter: 0:fix, 2:round-robin, 3:random
3:0 TIMOUTEN R/W 0 Bus timeout enable: detect slave no reaponse in 1024 cy-
cles
