BL702/704/706 Reference Manual
3.3.25 GPIO_CFGCTL7
Address：0x4000011c
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD GP15FUNC RSVD GP15
PD
GP15
PU
GP15DRV GP15
SMT
GP15
IE
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD GP14FUNC RSVD GP14
PD
GP14
PU
GP14DRV GP14
SMT
GP14
IE
Bits
Name Type Reset Description
31:29 RSVD
28:24 GP15FUNC R/W 5’hB GPIO Function Select (Default : SWGPIO )
23:22 RSVD
21 GP15PD R/W 0 GPIO Pull Down Control
20 GP15PU R/W 0 GPIO Pull Up Control
19:18 GP15DRV R/W 0 GPIO Driving Control
17 GP15SMT R/W 1 GPIO SMT Control
16 GP15IE R/W 1 GPIO Input Enable
15:13 RSVD
12:8 GP14FUNC R/W 5’hB GPIO Function Select (Default : SWGPIO )
7:6 RSVD
5 GP14PD R/W 0 GPIO Pull Down Control
4 GP14PU R/W 0 GPIO Pull Up Control
3:2 GP14DRV R/W 0 GPIO Driving Control
1 GP14SMT R/W 1 GPIO SMT Control
0 GP14IE R/W 1 GPIO Input Enable
