BL702/704/706 Reference Manual
3.3.29 GPIO_CFGCTL11
Address：0x4000012c
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD GP23FUNC RSVD GP23
PD
GP23
PU
GP23DRV GP23
SMT
GP23
IE
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD GP22FUNC RSVD GP22
PD
GP22
PU
GP22DRV GP22
SMT
GP22
IE
Bits
Name Type Reset Description
31:29 RSVD
28:24 GP23FUNC R/W 5’hB GPIO Function Select (Default : SWGPIO )
23:22 RSVD
21 GP23PD R/W 0 GPIO Pull Down Control
20 GP23PU R/W 0 GPIO Pull Up Control
19:18 GP23DRV R/W 0 GPIO Driving Control
17 GP23SMT R/W 1 GPIO SMT Control
16 GP23IE R/W 1 GPIO Input Enable
15:13 RSVD
12:8 GP22FUNC R/W 5’hB GPIO Function Select (Default : SWGPIO )
7:6 RSVD
5 GP22PD R/W 0 GPIO Pull Down Control
4 GP22PU R/W 0 GPIO Pull Up Control
3:2 GP22DRV R/W 0 GPIO Driving Control
1 GP22SMT R/W 1 GPIO SMT Control
0 GP22IE R/W 1 GPIO Input Enable
BL702/704/706 Reference Manual 64/ 375
