BL702/704/706 Reference Manual
3.3.32 GPIO_CFGCTL14
Address：0x40000138
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD GP29FUNC RSVD GP29
PD
GP29
PU
GP29DRV GP29
SMT
GP29
IE
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD GP28FUNC RSVD GP28
PD
GP28
PU
GP28DRV GP28
SMT
GP28
IE
Bits
Name Type Reset Description
31:29 RSVD
28:24 GP29FUNC R/W 5’hB GPIO Function Select (Default : SWGPIO )
23:22 RSVD
21 GP29PD R/W 0 GPIO Pull Down Control
20 GP29PU R/W 0 GPIO Pull Up Control
19:18 GP29DRV R/W 0 GPIO Driving Control
17 GP29SMT R/W 1 GPIO SMT Control
16 GP29IE R/W 1 GPIO Input Enable
15:13 RSVD
12:8 GP28FUNC R/W 5’hB GPIO Function Select (Default : SWGPIO )
7:6 RSVD
5 GP28PD R/W 0 GPIO Pull Down Control
4 GP28PU R/W 0 GPIO Pull Up Control
3:2 GP28DRV R/W 0 GPIO Driving Control
1 GP28SMT R/W 1 GPIO SMT Control
0 GP28IE R/W 1 GPIO Input Enable
