BL702/704/706 Reference Manual
3.3.31 GPIO_CFGCTL13
Address：0x40000134
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD GP27FUNC RSVD GP27
PD
GP27
PU
GP27DRV GP27
SMT
GP27
IE
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD GP26FUNC RSVD GP26
PD
GP26
PU
GP26DRV GP26
SMT
GP26
IE
Bits
Name Type Reset Description
31:29 RSVD
28:24 GP27FUNC R/W 5’hB GPIO Function Select (Default : SWGPIO )
23:22 RSVD
21 GP27PD R/W 0 GPIO Pull Down Control
20 GP27PU R/W 0 GPIO Pull Up Control
19:18 GP27DRV R/W 0 GPIO Driving Control
17 GP27SMT R/W 1 GPIO SMT Control
16 GP27IE R/W 1 GPIO Input Enable
15:13 RSVD
12:8 GP26FUNC R/W 5’hB GPIO Function Select (Default : SWGPIO )
7:6 RSVD
5 GP26PD R/W 0 GPIO Pull Down Control
4 GP26PU R/W 0 GPIO Pull Up Control
3:2 GP26DRV R/W 0 GPIO Driving Control
1 GP26SMT R/W 1 GPIO SMT Control
0 GP26IE R/W 1 GPIO Input Enable
