3.2.8 GPIO function setting
The function of GPIO is set through the GPIO_CFGCTL register group. The main setting items include:
• func_sel: select GPIO function
• pu: Choose whether to pull up
• pd: Choose whether to drop down
• drv: set drive capability
• smt: Choose whether to enable Schmitt trigger
• ie: set input enable
• oe: set output enable
The functions that GPIO can be set include:
• Flash/QSPI: Set GPIO as QSPI function, which can be connected to Flash as a program storage/running medium
• SPI: Set GPIO as SPI function
• I2C: Set GPIO as I2C function
• UART: Set GPIO as UART function
• PWM: set GPIO as PWM function
• ANA: Set GPIO as Analog function
• SWGPIO: set GPIO as general IO function
• JTAG: Set GPIO as JTAG function
• Other multiplexing functions
In order to meet customer needs as much as possible, each GPIO can basically select the above optional functions.
When an optional function is selected, GPIO and the corresponding function signal are shown in the following table:
Table 3.2: GPIO function table 1
GPIO
CLK_OUT Flash_PSRAM I2S SPI0 I2C UART PWM
GPIO0 clk_out[0] BCLK MISO/MOSI SCL SIG0/SIG4 PWM[0]
GPIO1 clk_out[1] FS MOSI/MISO SDA SIG1/SIG5 PWM[1]
GPIO2 clk_out[0] DIO/DO SS SCL SIG2/SIG6 PWM[2]
GPIO3 clk_out[1] RCLK_O/DI SCLK SDA SIG3/SIG7 PWM[3]
GPIO4 clk_out[0] BCLK MISO/MOSI SCL SIG4/SIG0 PWM[4]
GPIO5 clk_out[1] FS MOSI/MISO SDA SIG5/SIG1 PWM[0]
