BL702/704/706 Reference Manual
Bits
Name Type Reset Description
21 GP35PD R/W 0 GPIO Pull Down Control
20 GP35PU R/W 0 GPIO Pull Up Control
19:18 GP35DRV R/W 0 GPIO Driving Control
17 GP35SMT R/W 1 GPIO SMT Control
16 GP35IE R/W 1 GPIO Input Enable
15:6 RSVD
5 GP34PD R/W 0 GPIO Pull Down Control
4 GP34PU R/W 0 GPIO Pull Up Control
3:2 GP34DRV R/W 0 GPIO Driving Control
1 GP34SMT R/W 1 GPIO SMT Control
0 GP34IE R/W 1 GPIO Input Enable
3.3.36 GPIO_CFGCTL18
Address：0x40000148
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD GP37
PD
GP37
PU
GP37DRV GP37
SMT
GP37
IE
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD GP36
PD
GP36
PU
GP36DRV GP36
SMT
GP36
IE
Bits
Name Type Reset Description
31:22 RSVD
21 GP37PD R/W 0 GPIO Pull Down Control
20 GP37PU R/W 0 GPIO Pull Up Control
19:18 GP37DRV R/W 0 GPIO Driving Control
17 GP37SMT R/W 1 GPIO SMT Control
16 GP37IE R/W 1 GPIO Input Enable
15:6 RSVD
5 GP36PD R/W 0 GPIO Pull Down Control
4 GP36PU R/W 0 GPIO Pull Up Control
3:2 GP36DRV R/W 0 GPIO Driving Control
